Welcome to Modern Eastern services for Prefab Houses “MDEST” Prefab Houses

MDEST offers prefabricated building solutions and portable cabin houses in Kingdom of Saudi Arabia, MDEST Prefab houses manufactures porta cabins, prefab cabins, portable cabins and various prefab products and services which are integrated to meet customers’ needs, MDEST offers a complete range of prefabricated construction like porta hut, Roofing, Ceilings, Walls, Floors, Cladding, mobile office and for the Industrial, Commercial and Residential Sectors in Prefabs type houses. Today, MDEST is one of the most respected and renowned business entities in Kindom of Saudi Arabia and has gained a strong foothold in the market for all types of porta cabin in K.S.A, The company has a pan KSA presence with a large distribution network for all types of prefabricated structures like portable office or porta hut. Banking on its state-of-the art manufacturing facilities and an employee strength of highly qualified and experienced designers, technicians and fabricators. MDEST assures that all its Prefab products live up to its age old promise of Quality, Strength, Speed and Safety. We are the manufacturers of Prefab Cabins, Prefabricated Structures, Portable Cabins, Porta Cabins, Portable Offices, Container Office and all types of modular structures and buildings.

TECHNICAL SPECIFICATION

Base Frame

The base frame is made of structure steel members of different profiles (12/6) welded together. All steel members are primed for weather protection and painted in black.(The height of Legs are 30cm and block size is 30x30cm). Cross beams IPE 120 at the gables Internal cross beams IPE 120 with lifting lugs.

Floors

A Sub Floor is girders are steel tubes 40 x 40 mm thickness 1.2 every 40 cm centre to center B Floor Deck is made up 18 mm thick plywood boards screwed to the sub floor joists. C Floor Covering is of 4 mm thick carpet in room except in wet areas and corridor shall be of 2 mm thick vinyl sheeting or vinyl asbestos for Kitchens. Wet areas shall be covered with P.V.C sheeting.

Walls

External walls are 5 cm thick made of prefabricated foam panels with polystyrene insulation, clad inside with 4 mm decorative plywood (panel system) insulated with expanded and from outside with 0.35 mm pre-coated steel sheets (off-white color) internal walls are 50 mm thick, clad from both sides with decorative plywood insulated with expanded polystyrene. Partitions are constructed of insulated foam panels 50 mm thick covered on both sides with decorative plywood boards. Wall joints the wall to floor joints shall be covered with wooden skirting.

Roofs and Ceilings

The roof is made of steel trusses and steel angle purtins to which white corrugated pre-finished sheets roofing are fixed. The roof coming with insulation fiberglass 5 cm thick. Ceilings are covered with arm storm (60x60cm) and insulation layer 20 cm thick. or 4mm white water proof ply and the clear height is about 240 cm from the finished floor level.

Windows

Windows are made of aluminum section completed with fly screens. The glass coming with save steel inside. Size 100x100 cm

Doors

Internal doors are made of a wooden frames and are covered both sides with the same decorative plywood boards used for internal walls. External doors are covered externally with pre painted sheeting and decorative plywood boards internally.

Electrical

Each room is provided with one double florescent (2*40w) covert one light switch, one socket for a/c and one extra socket. PVC conduits are imbedded inside the walls to accommodate all wirings. All the electric lines are connected to a main panel board with breakers. 220 volts, telephone lines can be fixed as per your order.

Sanitary

Bathrooms wall of bathrooms are covered with water resistant sheets. Each bathroom is provided with European water closet, wash basin with mixer, shelf. Ablution P.V.C sheeting, water resistant plywood & drainage system. Kitchens walls are similar to bathroom walls. Each kitchen is provided with a stainless steel sink with mixer, P.V.C Tiles & drainage system. Any specification we can change as per your order.
